The high-energy permanent magnet inside a high speed drum creates a strong electromagnetic induction phenomenon on the surface of the drum.
When the aluminum, copper, brass and magnesium (high conductive materials) pass through this magnetic field, the eddy current occurs repelling them respective to their conductivity thereby pushing each the distance determined by Fleming’s left hand law creating separate piles for each type of material.
[Usage]
1. Recovery aluminum cans from plastic and glass bottles.
2. High efficiency of recovery of aluminum from city waste.
3. Separation of nails and iron steels from crushed machines.
4. Recovery of valuable metals from glass cullet.
[Features]
1. 2 models for material size. ALS-L for large objects like cans & ALS-S for small objects.
2. Parallel usage with vibration feeder provides stable feeding volume and increase separation efficiency.
[Specifications]
1. Magnetic Drum Speed : ALS-L (Max. 1,800rpm) ALS-S (Max. 2,500rpm)
2. Including a controller unit
3. Belt drive with hypoid gear motor.
